SMART Backend Authentication in FHIR System

Overview

SMART (Substitutable Medical Applications, Reusable Technologies) backend authentication in an FHIR (Fast Healthcare Interoperability Resources) system enables system-to-system authentication without direct user interaction. It uses OAuth 2.0 client credentials and JWT-based authentication to securely access FHIR resources.

Key Components

1. OAuth 2.0 with Client Credentials Grant
   • The backend service authenticates using client credentials (client ID and secret).
   • It requests an access token from the FHIR authorization server.
2. JWT-Based Authentication
   • The backend client generates a JWT (JSON Web Token) signed with its private key.
   • The JWT is used to request an OAuth 2.0 access token.
   • JWKS submitted to FHIR Server to know your RSA key pair and validate the authentication request. There are different ways to share jwks with server to effienctly know any change in keys or rotation of keys.
3. Scopes and Permissions
   • Access is controlled via FHIR scopes, e.g.:
     • system/*.read → Read all system-wide FHIR resources.
     • system/Patient.read → Read patient resources only.
4. Access Token Usage
   • Once authenticated, the backend service uses the access token to make FHIR API calls.
   • The FHIR server verifies the token before processing the request.

---

Implementation Steps

Requirements

Install the required Python dependencies:

pip install cryptography jwcrypto pyjwt

Step 1: Generate RSA Key Pair

Run the Python script generate_keys.py to generate an RSA private-public key pair.

python generate_keys.py

This will generate:

• private_key.pem → The private key.
• public_key.pem → The public key.
• jwks.json → The JSON Web Key Set (JWKS) file.

Step 2: Use JWT for Authentication

After generating the RSA keys, a JWT can be created and signed with the private key to request an OAuth 2.0 access token. We can use create_jwt_assertion.py script to generate JWT assertion for authentication flow.

Example – JWT Assertion

Generated JWT Assertion:
eyJhbGciOiJSUzM4NCIsInR5cCI6IkpXVCIsI..

Step 3: Request an OAuth 2.0 Token

Once the JWT is signed, exchange it for an access token.

Example Token Request

POST /token HTTP/1.1
Host: auth.fhirserver.com
Content-Type: application/x-www-form-urlencoded

grant_type=client_credentials
&client_assertion_type=urn:ietf:params:oauth:client-assertion-type:jwt-bearer
&client_assertion=eyJhbGciOiJSUzM4NCIsInR5cCI6IkpXVCIsI..
&scope=system/*.read

Step 4: Use Access Token for FHIR API Calls

Include the access token in API requests:

Example API Request

GET /fhir/Patient HTTP/1.1
Host: fhirserver.com
Authorization: Bearer <access_token>

Conclusion

By following the above steps, you can implement SMART Backend Authentication in an FHIR system, ensuring secure system-to-system communication using JWT, OAuth 2.0, and RSA keys.
